WARN WINCH SERIES 18 HYDRAULIC

Description

Hydraulic Pulling Power of up to 18,000 lbf. (Single line)

• For tow, utility and trailer applications
• 7.3 cubic-inch hydraulic motor
• Hardened steel two-stage planetary geartrain with 36:1 reduction provides fast line speed
• Heavy-duty disc brake for dependable operation and plenty of holding power
• Meets SAE J706 and CE specifications
• Wire rope, roller fairlead, and tensioner sold separately

Data:
Rated Pulling Force: 18000 lbf. (8165 kgf)
Drum Barrel Diameter: 4.0 in (102mm)
Drum Flange Diameter: 8.24 in (209 mm)
Distance Between Flanges: 9.95 in (253 mm)
Recommended Maximum Wire Rope Diameter: 1/2 in (12.7 mm)
Recommended Minimum Wire Rope Breaking Strength: 26600 lbf (12066 kgf)
Approximate Shipping Weight: 82.0 lb (37.2 kg)
Duty Cycle (intermittent per SAE J706 section 6.2): 565 ft (172 m)
Mounting Bolt Torque: 35-40 ft*lbf (47-54 N*m)
Maximum Layers of Wire Rope: 3 (with 1/2″ dia. rope)
Gear Reduction: 36:1
Brake Type: Disk
Contactor / Remote Type: N/A
Standards Compliance:
SAE J706
CE Machinery Directive 98/37/EC and 006/42/EC

Accessory:
Wire Rope Tension Plate 10”: PN 31149
Fairlead Black 10”: PN 24336
Fairlead Chrome 10″: PN 30859
Remote Clutch Mechanical: PN 38316
Remote Clutch Air: PN 71370
Wire Rope Assembly 1/2”x75′ EIPS: PN 77534
